Lightware MMX6x2-HT200 User Manual

MMX6x2-HT
User’s Manual
Section 10. Appendix Page 115 / 119
10.4. Input and output port numbering
Port name
Video
port no.
Audio
port no.
EDID
memory
RS-232
port no.
TPS input #1
I1
I1
E1
P2
TPS input #2
I2
I2
E2
P3
HDMI input #3
I3
I3
E3
-
HDMI input #4
I4
I4
E4
-
HDMI input #5
I5
I5
E5
-
HDMI input #6
I6
I6
E6
-
HDMI output #1
O1
O1
D1
-
HDMI output #2
O2
O2
D2
-
TPS output #1 *
O3
O3
D3
P4
TPS output #2 **
O4
O4
D4
P5
Analog audio input #1
-
I7
-
-
Analog audio input #2
-
I8
-
-
Analog audio input #3
-
I9
-
-
Analog audio input #4
-
I10
-
-
Analog audio output #1
-
O5
-
-
Analog audio output #2
-
O6
-
-
Local RS-232
-
-
-
P1
Mirrored outputs: O1-O3 and O2-O4.
* Only on MMX6x2-HT210 and MMX6x2-HT220 devices.
** Only on MMX6x2-HT220 device.
10.5. Maximum twisted pair distances
Resolution
Pixel clock
rate
Cable lengths ( Auto / Longreach TPS mode)
CAT5e
AWG24
CAT7
AWG26**
CAT7
AWG23
1024x768@60Hz
65 MHz
100 m / 130 m*
90 m / 120 m*
120 m / 170 m*
1280x720p@60Hz
73.8 MHz
100 m / 130 m*
90 m / 120 m*
120 m / 170 m*
1920x1080p@60Hz / 24bpp
148.5 MHz
100 m / 130 m*
90 m / 120 m*
120 m / 170 m*
1920x1200@60Hz
152.9 MHz
100 m / NA
90 m / NA
120 m / NA
1600x1200@60Hz
162 MHz
100 m / NA
90 m / NA
120 m / NA
1920x1080@60Hz / 36bpp
223.6 MHz
70 m / NA
70 m / NA
100 m / NA
3840x2160@30Hz UHD
297 MHz
70 m / NA
70 m / NA
100 m / NA
4096x2160@30Hz 4K
297 MHz
70 m / NA
70 m / NA
100 m / NA
* With Long reach operation mode which supports pixel clock frequencies up to 148.5 MHz.
** When remote powering is used with AWG26 cables, distances are 20% shorter.
