MMX6x2-HT
User’s Manual
Section 6. Software control – Using Lightware Device Controller Page 59 / 119
6.8.1. The Event editor
Press the Edit button in the desired Event line to open the Event editor window.
Event header The name of the Event is displayed. Type the desired name and
press the Set name button. The Event can be cleared by the
Clear button. Use the tick mark to enable/disable the Event.
Condition header If the condition is set, the description (white colored text) and the
exact LW3 protocol expression (yellow colored text) can be seen.
If the advanced mode was used the description is “Custom
condition”.
Condition panel The Wizard, the Advanced or the Link tool is available to set the
condition. The parameters and settings are displayed below the
buttons.
Condition test The set condition can be tested to see the working method in the
practice.
Delay settings The action can be scheduled to follow the condition after the set
time value.
Action header If the action is set, the description (white colored text) and the
exact LW3 protocol expression (yellow colored text) can be seen.
If the advanced mode was used the description is “Custom
action”.
Action panel The Wizard, the Advanced or the Link tool is available to set the
action. The parameters and settings are displayed below the
buttons.
Action test The set action can be tested to see the working method in the
practice.
