Lightware MMX6x2-HT200 User Manual

MMX6x2-HT
User’s Manual
Section 7. LW2 programmers’ reference Page 69 / 119
7.2.9. Restart matrix router
Description: The device can be restarted without unplugging power.
Format
Example
Command
{RST}
→
{RST}
Response
Explanation: The device reboots; no response is sent in this case.
7.2.10. Query health status
Description: Internal voltages and measured temperature values are shown.
Format
Example
Command
{ST}
→
{st}
Response
(ST●<DESC>)CrLf
←
(ST CPU 1.03V 1.03V 1.03V 1.82V
1.34V 1.35V 3.31V 5.06V 48.00V
46.81C 51.12C 0.00C 40.25C
51.12C)CrLf
7.2.11. Restore factory default settings
Description: Settings can be reset to factory default values as follows:
Format
Example
Command
{FACTORY=ALL}
→
{factory=all}
Response
(FACTORY ALL…)CrLf
←
(FACTORY ALL…)CrLf
Explanation: All settings and parameters are reset to factory default, see the table in
section 10.6 on page 116.
7.3. Port and crosspoint settings
7.3.1. Switch one input to one output
Description: Switch input <in> to output <out>.
Format
Example
Command
{<in>@<out>}
→
{2@1}
Response
(O<out²>●I<in²>)CrLf
←
(O01 I02)CrLf
Explanation: Input 1 is switched to output 2.
ATTENTION!
The response of this command does not show if the output is muted. To check the mute
status a separate query has to be used like {VC}. See section 7.3.6 on page 69. To achieve
multiple switches executed together, see section 7.3.8 on page 70.
7.3.2. Mute specified output
Description: Mute output <out>. The output signal is turned off.
Format
Example
Command
{#<out>}
→
{#01}
Response
(1MT<out²>)CrLf
←
(1MT01)CrLf
Explanation: O1 port is muted.
ATTENTION!
Muting does not change the crosspoint’s state but disables the output itself. This way the
last connection can be easily restored with an unmute command. Switching a muted output
does not unmute the output.
