10.6. Factory default settings
Parameter
Setting/Value
Network settings
IP address
192.168.0.100
Subnet mask
255.255.255.0
Static gateway
192.168.0.1
LW2 Port number
10001
LW3 Port number
6107
HTTP Port number
80
DHCP
disabled
TPS and HDMI port settings
HDCP – on input ports
Enabled
HDCP – on output ports
Auto
Output TPS mode (on TPS output ports)
Auto
Output HDMI mode
Auto
Power 5V mode
Auto
No sync screen mode
Off
No sync screen color
Bar
No sync screen resolution
480p
Crosspoint state
HDMI I3 @ O1 & O3; HDMI I4 @ O2 & O4
Audio source
Embedded audio
Autoselect
Disabled
Autoselect video priority (from 0 to 5)
I1, I2, I3, I4, I5, I6
PoE feature
Enabled
Emulated EDID*
F47 - Factory (1920x1080@60Hz HDMI)
Analog audio port settings
Volume
0.00 dB
Balance
50 (center)
Gain
0.00 dB
RS-232 settings
Control protocol
LW2
Baud rate
57600
Databits / Parity / Stopbits
8 / No / 1
Operation mode (local and link ports)
CI (Command Injection)
Command Injection port nr. (Local)
8001
Command Injection port nr. (TPSIN1)
8002
Command Injection port nr. (TPSIN2)
8003
Command Injection port nr. (TPSOUT1)
8004
Command Injection port nr. (TPSOUT2)
8005
* The default EDID has been changed since firmware 1.1.0. The default EDID for firmware
1.0.0 is D1, dynamic.
