Lightware MMX6x2-HT200 User Manual

Page 96 / 119 Section 8. LW3 Programmers’ reference
Gain
Command format
SET/MEDIA/AUDIO/<On>.Gain=<level>
Response format
pw/MEDIA/AUDIO/<On>.Gain=<level>
Parameters
<level> Sets the output gain which can be 0, 1, 2 or 3 dB. The value is rounded
down if necessary to match with the step value.
Example
> SET/MEDIA/AUDIO/O5.Gain=2
< pw/MEDIA/AUDIO/O5.Gain=2
Mute / Unmute
Command format
SET/MEDIA/AUDIO/<On>.MuteSetting=true|false
Response format
pw/MEDIA/AUDIO/<On>.MuteSetting=true|false
Example
> SET/MEDIA/AUDIO/O5.MuteSetting=true
< pw/MEDIA/AUDIO/O5.MuteSetting=true
8.7. RS-232 port configuration
ATTENTION!
MMX6x2 handles many serial ports. The following parameters can be set individually on
each port; the exact port numbering is listed in section 10.4 on page 115.
8.7.1. Protocol setting
Command format
SET/MEDIA/UART/<Pn>.ControlProtocol=0|1
Response format
pw/MEDIA/UART/<Pn>.ControlProtocol=0|1
Parameters
.ControlProtocol
0
1
Selected protocol
LW2
LW3
Example
> SET/MEDIA/UART/P1.ControlProtocol=1
< pw/MEDIA/UART/P1.ControlProtocol=1
