Technical Information
29
PW 6xx7
Item number in table Item description Options Details
18 Hot water control Yes / No
With the setting Yes and
water intake control set to
Automatic, the water inlet
valves are operated in a
certain way. If possible, the
control will attempt to
achieve the desired wash
cycle temperature during the
first water intake by
operating the cold and hot
water valves alternately.
Without the water intake
control set to Automatic, the
control opens the
programmed valves until the
target temperature is
reached and then switches
to cold water intake only.
Default factory setting: No.
19 Price No / 0.10, 0.20, ...,
9999.90 in 0.10
steps
Here the price of a wash
program is set on models
with a payment system. No
charge can be set or a price
between 0.10 currency units
to 9999.90 currency units.
Default factory setting: No.
Table 100-6: Internal Structure of Program Header for a Profitronic M Washing
Program
Model, program and maximum load table:
Model PW 6107 PW 6137 PW 6167 PW 6207
Drum volume 100L 130L 160L 200L
Cottons 90ºC 10kg 13kg 16kg 20kg
Colors 60ºC 10kg 13kg 16kg 20kg
Colors intensive 60ºC 10kg 13kg 16kg 20kg
Colors 30ºC 10kg 13kg 16kg 20kg
Colors intensive 30ºC 10kg 13kg 16kg 20kg
Short program 10kg 13kg 16kg 20kg
Minimum iron 60ºC 5kg 6.6kg 8kg 10kg
Minimum iron intensive 60ºC 5kg 6.6kg 8kg 10kg
Minimum iron 30ºC 5kg 6.6kg 8kg 10kg
Minimum iron intensive 30ºC 5kg 6.6kg 8kg 10kg
Delicates 2kg 2.6kg 3.2kg
4kg
Woolens 30ºC 4kg 5.2kg 6.4kg 8kg
Hand-washable woolens 30ºC 4kg 5.2kg 6.4kg 8kg
Table 100-7: Maximum Laundry Loads (in Kilos of Dry Laundry) in Relation to
Washing Machine Program and Model
2.3 Programming
In general, a Profitronic M washing program consists of 3 program areas:
program area 1, program area 2 and program area 3, each of which has a
maximum of 10 blocks. Each block is individually programmable and consists
of 36 program steps. The smallest practical program has one area and one
block (theoretically, 0 areas with 0 blocks is possible). The most complex
program can have 3 areas each with 10 blocks.
Blocks always have the same basic structure. Block programming involves
completing the block name field and setting the parameters for the remaining
