FOURTH GEAR
POWER TRAIN
-
Manual Transaxle
2-15
/
The 3-4 synchronizer sleeve moves rearward to
I/
engage the fourth-speed gear clutch teeth. Input
sleeve, fourth speed gear and the output shaft. The
output shaft pinion gear turns the differential ring
power goes through the input shaft, into the 3-4
gear. The gear ratio for fourth is
1.03:1
synchronizer hub. The hub turns the synchronizer
4th speed
gear
3-4 synchronizer
sleeve
0475-056
