EQUIPMENT
-
Lighting
7-9
Dome light
(Vehicles with sunroof)
\
Dome light
(Vehicles without sunroof)
Headlight (front turn
signal and front
\
/
position light)
\
-Y
A16XOO23
/
Fog light
Front side marker
light
Foot light
Foot light
.
\
HEADLIGHT
ON-BOARD AIMING MECHANISM
The vertical aiming adjustment can be made by
turning the vertical adjusting screw to bring the
bubble of the vertical adjusting gauge to the position
between the adjusting marks.
CO854
i
High-mounted stop light
(bulb
ty?
<Vertical adjusting>
\\.Arc*
_
4-k
Adjusting mark
,
light
Rear combination light
Al
6X0024
Back-up light
The horizontal aiming adjustment can be accom-
plished by turning the horizontal adjusting screw
to align the
“0”
mark of the gear (B) with the line
of the stopper and that of the headlight housing.
:Horizontal
adjusting>
To Next Page
