2-16
POWER TRAIN
-
Manual Transaxle
FIFTH GEAR
AZ=-.
r
\
\
-
I
5th speed gear
J=&EzT
The 5-R synchronizer sleeve moves forward to
en-
gage the fifth-speed gear clutch teeth. Input power
goes through the input shaft, into the 5-R
synchroniz-
er hub. The hub turns the synchronizer sleeve, the
fifth speed gear and the output shaft. The output
shaft pinion gear turns the differential ring gear.
The gear ratio for fifth is 0.81
:l
,,d
5-R
synchronizer
sleE
we
0475-067
128
130
