POWER TRAIN
-
Manual Transaxle
The assembly consists of the output shaft, l-2
syn-
chronizer assembly, first and second speed gears,
snap rings and needle bearings. First and
second-
speed gears use caged needle bearings that rotate
on the shaft journals. Third, fourth and fifth gears
are heated and pressed on the output shaft.
Individu-
al components are not serviceable because of the
heat and press operations, if any of the components
fail the entire assembly must be replaced.
‘L/
1.
Output shaft
2. First gear bearing
9. Second gear bearing
10.
Inner cone
3. First speed gear
11.
Outer cone
4. First gear stop ring
5.
Outer cone
12. Second gear storing
6.
Inner cone
13. Second speed gear
7.
l-2 synchronizer
14. Third and fourth gears
15.
Fifth
8. l-2 synchronizer snap ring
gear
16. Fifth gear snap ring
0475-042
