8-4
Chapter 8 FUEL SYSTEM
1.2 Fuel Leak-off Pipe and Fuel Pipe - Remove and Inspect
Fuel Leak-off Pipe and Fuel Pipe - Remove and Inspect
1
7
8
9
10
11
12
Replace
A
A
With fuel filter (wire element) spec
Return to fuel tank
3
6
6
2
4
5
Replace
Replace
Replace
Replace
Removing Sequence
1 Left leak-off pipe
2 Left leak-off pipe
3 Leak-off pipe
4 Right leak-off pipe
5 Right leak-off pipe
6 Fuel pipe
7 Fuel pipe
8 Fuel pipe
9 Leak-off connector
10 Fuel filter (wire mesh element)
(Fuel filter [wire mesh element] spec)
11 Left leak-off pipe
12 Right leak-off pipe
