10-25
Chapter 10 COOLING SYSTEM
2.5
Thermostat - Disassem
ble and In
spect
Thermostat - Disassemble and Inspect
1
2
1
2
1
2
3
4
30 ± 3.0 N·m
{3.0 ± 0.3 kgf·m}
[22.1 ± 2.2 lbf·ft]
Replace
Replace
MPT
A,
MPTK spec
PT
A,PT
A2,PTK,
PT
A
W spec
MTK spec
Disassembling Sequence
1
Thermostat cover
2
Packing
3
Thermostat
4
Thermostat case
