11-3

Chapter 11 INLET AND EXHAUST SYSTEMS

1. Inlet and Exhaust Systems - Remove and Inspect

1.1 Air Duct and Air cooler - Remove and Inspect

Air Duct and Air cooler - Remove and Inspect

Crack, flaw, deformation

PTA,PTK,MPTA spec

Crack, flaw, deformation

Replace

Turbocharger

Crack, flaw,

deformation

Replace

Removing Sequence

1 Connector

2 Air duct

3 Air cooler (approx. 57 kg [125 lb.])

4 Spacer
