Motorola ASTRO SPECTRA Service Manual

February 3, 2003 6881076C20-E
9-2 Basic Troubleshooting: Power-Up Error Codes
9.3.1 ASTRO Digital Spectra
Table 9-1. ASTRO Digital Spectra Power-Up Error Codes
Error Code Description Corrective Action
01/02 External EEPROM checksum
non-fatal error
Reprogram the codeplug.
01/81 ROM checksum failure Reprogram the FLASH memory.
01/82 External EEPROM checksum
failure
Reprogram the codeplug.
01/84 EEPROM is blank Program the EEPROM.
01/88 RAM failure - Note: not a
checksum failure
Turn the radio off, then on.
01/90 General hardware failure Turn the radio off, then on.
01/92 Internal EEPROM checksum
failure
Reprogram the codeplug.
02/10 DSP support IC checksum non-
fatal error
Turn the radio off, then on.
02/81 DSP ROM checksum failure Reprogram the FLASH memory.
02/82 DSP RAM 1 failure Replace the VOCON board.
02/84 DSP RAM 2 failure Replace the VOCON board.
02/88 DSP RAM failure - Note: not a
checksum failure
Turn the radio off, then on.
02/90 General DSP hardware failure
(DSP startup message not
received correctly)
Turn the radio off, then on.
02/A0 ADSIC checksum failure Replace the VOCON board.
05/10 Control head not communicating
with radio
Turn the radio off, then on.
05/81 Control head ROM checksum
failure
Replace the control head.
08/10 Siren/PA not communicating with
radio
Turn the radio off, then on.
09/10 Secure option not
communicating with radio
Turn the radio off, then on.
