Motorola ASTRO SPECTRA Service Manual

February 3, 2003 6881076C20-E
9-4 Basic Troubleshooting: Operational Error Codes
9.4 Operational Error Codes
During radio operation, the radio performs dynamic tests to determine if the radio is working properly.
Problems detected during these tests are presented as error codes on the radio’s display. The
presence of an error code should prompt a user that a problem exists and that a service technician
should be contacted. Use the following tables to aid in understanding particular operational error
codes.
9.4.1 ASTRO Digital Spectra
FAIL 08/81 Siren ROM Checksum
Error
FATAL Replace the siren.
ERROR 09/10 Secure Hardware Error NON-
FATAL
Replace the secure module.
FAIL 09/90 Secure Hardware Fatal
Error
FATAL Replace the secure module.
ERROR 12/10 VRS Hardware Error NON-
FATAL
Turn the radio off, then on.
FAIL 12/81 VRS ROM Checksum
Error
FATAL Replace the VRS.
ERROR 1C/10 TRC Hardware Error NON-
FATAL
Turn the radio off, then on.
FAIL 1C/81 TRC ROM Checksum
Error
FATAL Replace the TRC.
Table 9-3. ASTRO Digital Spectra Operational Error Codes
Error Code Description Corrective Action
FAIL 001 Synthesizer Out-of-Lock 1. Reprogram codeplug
2. Replace RF board.
FAIL 002 Selected Mode/Zone Codeplug
Checksum Error
Reprogram codeplug.
Table 9-2. ASTRO Digital Spectra Plus Power-Up Error Codes (Continued)
Error Code Description
Error
Type
Corrective Action
