4-6 Test Equipment, Service Aids, and Tools: Field Programming Equipment
The following items, available through the Customer Care and Services Division (except the
computer), are required when programming ASTRO Digital Spectra Model radios.
4.3.1.1 ASTRO Digital Spectra W3 Smart RIB Issue
When flashing a Model W3 mobile radio, the smart RIB box tends to reset if the correct power-up
sequence is not observed. To avoid this problem, you must power up the radio before you use the
smart RIB box. You might damage the control head or the RIB box if you use a modified RIB box to
flash Model W3 radios.
4.3.1.2 ASTRO Digital Spectra Remote W3 Y Cable
The remote Y cable required for high-power Model W3 radios cannot be used for programming. The
accessory connector in this cable does not have the BUS+, BUS-, and BUSY lines.
Table 4-8. ASTRO Digital Spectra Field Programming Items
Type or Part Number Description
01-80300B10
Programming Cable
Used to connect high-power radios (50W-110W) directly
to the RIB or SRIB.
30-80369B71
Computer Interface Cable
RLN-4008 RIB-to-computer cable. For computers with a
25-pin serial (COM) port.
30-80369B72
Computer Interface Cable
RLN-4008 RIB-to-computer cable. For computers with a
9-pin serial (COM) port.
30-80369B73
Programming Cable
RIB-to-radio programming cable for low- and mid-power
radios.
30-80390B48
Computer Interface Cable
RLN-1015 SRIB-to-computer cable. For computers with
a 9-pin serial (COM) port.
30-80390B49
Computer Interface Cable
RLN-1015 SRIB-to-computer cable. For computers with
a 25-pin serial (COM) port.
Computer, IBM or IBM PC-
compatible
CVN-6085 Radio Service
Software (3-1/2” disks)
Software that provides the capability of changing the
radio frequencies, squelch codes, and other radio
parameters. Replaces RVN-4100.
RLN-1015A
Smart Radio Interface Box
(SRIB)
A voltage-level shifter to enable communications
between the radio and the computer’s RS-232 port.
Allows use of FLASHport technology.
RLN-4008B
Radio Interface Box (RIB)
A voltage-level shifter to enable communications
between the radio and the computer’s RS-232 port.
RPX-4719 Radio Service
Software Package
Kit containing software licensing agreement, software
order forms, and a list of available software. Must be
ordered prior to ordering any software.
RKN-4047A EEPROM
Flash Program
Interface Cable
Used to load the radio with new features using
FLASHport technology. Requires RLN-1015 SRIB.
