Motorola ASTRO SPECTRA Service Manual

6881076C20-E January 29, 2003
Model Numbering, Charts, and Specifications xxi
ASTRO Digital Spectra VHF 10–25 and 50–110 Watt Model Chart (cont.)
Model Number Description
D04JKH9PW3AN Model W3 (136-145.9 MHz), 25-50 Watt, 128 Channels
D04JKF9PW4AN Model W4 (136-162 MHz), 25-50 Watt, 128 Channels
D04JKF9PW5AN Model W5 (136-162 MHz); 25-50 Watt, 128 Channels
D04JKH9PW7AN Model W7 (136-162 MHz), 25-50 Watt, 255 Channels
T04JKH9PW9AN Model W9 (136-162 MHz), 25-50 Watt, 255 Channels
D04KKF9PW3AN Model W3 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKF9PW4AN Model W4 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKF9PW5AN Model W5 (146-174 MHz), 25-50 Watt, 128 Channels
D04KKH9PW7AN Model W7 (146-174 MHz), 25-50 Watt, 255 Channels
T04KKH9PW9AN Model W9 (146-174 MHz), 25-50 Watt, 255 Channels
T04JLH9PW3AN Model W3 (136-145.9 MHz), 50-110 Watt, 128 Channels
T04JLF9PW4AN Model W4 (136-162 MHz), 50-110 Watt, 128 Channels
T04JLF9PW5AN Model W5 (136-162 MHz), 50-110 Watt, 128 Channels
T04JLH9PW7AN Model W7 (136-162 MHz), 50-110 Watt, 255 Channels
T04JLH9PW9AN Model W9 (136-162 MHz), 50-110 Watt, 255 Channels
T04KLH9PW3AN Model W3 (146-174 MHz), 50-110 Watt, 255 Channels
T04KLF9PW4AN Model W4 (146-174 MHz), 50-110 Watt, 128 Channels
T04KLF9PW5AN Model W5 (146-174 MHz), 50-110 Watt, 128 Channels
T04KLH9PW7AN Model W7 (146-174 MHz), 50-110 Watt, 255 Channels
T04KLH9PW9AN Model W9 (146-174 MHz), 50-110 Watt, 255 Channels
Item No. Description
X XXXXXXXXXHLN6132_* High-Power Installation Hardware
XX
XX XXXX HLN6015_ Trunnion/Hardware (Dash Mount)
XX
XX XXXX HLN6060_ Dash-Mount Hardware
X XXXXXXXXXHLN6121_* High-Power Radio Hardware
XX
XXXXXXXX HLN6418_* Transceiver Hardware
X X X X HLN6440_* Control Head without Keypad Hardware
X X X X HLN6441_* Control Head with Keypad Hardware
X XXXXXXXXXHLN6525_* High-Power Transceiver Hardware
X X XXX X HLN6493_* Plug Kit
X XXXXXXXXXXHLN4952_ Fuse Kit
X X XXXXXXXXHKN4356_ Radio Cable (Length -17 Feet)
X XXXXXXXXXHKN6039_ Cable (Length - 17 Feet)
X XXXXXXXXXHKN4051_ Cable and Fuse
XX
XX XXXX HKN4191_ Power Cable (Length - 20 Feet)
X X HKN4192_ Power Cable (Length - 20 Feet)
X X X X HLN6481_* Systems 9000 E9 Clear Button Kit
X
X X X HLN6549_* C4 Button Kit
X
X X X HLN6105_ Emergency/Secure/MPL Button Kit
XX X X XX X X HLN6193_ Emergency/MPL Field Option Button Kit
X X X X HLN6548_* SMARTNET Button Kit
X X X X HLN6523_* SMARTNET Button Kit
X X X X HLN6167_ Option Button Kit
X
X HLN6459_ W3 Interface Board Kit
X
X X X HMN4044_ ASTRO Handheld Control Head (W3)
X
X X X TLN5277_ Filter Kit
X X HKN6096_ Handheld Control Head “Y” Cable Kit
X X HLN6291_ Installation Hardware Kit
X X HLN6574_ W3 Interconnect Board Kit
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
