Motorola ASTRO SPECTRA Service Manual

January 29, 2003 6881076C20-E
xxii Model Numbering, Charts, and Specifications
ASTRO Digital Spectra UHF 10–25 Watt Model Chart
Model Number Description
D04RHH9PW3AN Model W3 (438-470 MHz), 10-25 Watt, 255 Channels
D04RHF9PW4AN Model W4 (438-470 MHz), 10-25 Watt, 128 Channels
D04RHF9PW5AN Model W5 (438-470 MHz), 10-25 Watt, 128 Channels
D04RHH9PW7AN Model W7 (438-470 MHz), 10-25 Watt, 255 Channels
T04RHH9PW9AN Model W9 (438-470 MHz), 10-25 Watt, 255 Channels
Item No. Description
X AAHN4045_ Front Housing
X
XXX X HAE4003_ Antenna
X
XXX HKN4191_ Power Cable (Length-20 Feet)
X
XXX X HLE6046_ VCO Carrier, Range 2
X
XXX X HLE6062_ Power Amplifier, 25W, Range 2
X
XXX X HLE6102_ VCO Hybrid Kit, Range 2
X
XXX X HLN5558_ Command Board Kit
X
XXX HLN6015_ Trunnion
XXX HLN6073_ Dash-Mount Hardware
X HLN6105_ Emergency/Secure/MPL Button Kit
X HLN6549_* C4 Button Kit
XXX HLN6401_ Control Head Interconnect Board
X
XXX X HLN6418_* Transceiver Hardware
X
XXX X HLN6458_ VOCODER Controller
XXX HMN1080_ Microphone
X
XXX X HRE6002_ Receiver, Range 2
XXX X HRN6020_ RF Board Kit
X
XXX X HSN4018_ Speaker
X HLN6548_* SMARTNET Button Kit
X X HLN6193_ Emergency/MPL Field Option Button Kit
X X HLN6396_ DEK Compatible Control Head
X HLN6440_* Control Head without Keypad Hardware
X HLN6441_* Control Head with Keypad Hardware
X HLN6523_* SMARTNET Button Kit
X HCN1078_ W9 Control Head
X HKN4192_ Power Cable (Length-20 Feet)
X HKN4356_ Radio Cable
X HLN4921_ Trunnion
X HLN4952_ Fuse Kit
X HLN5488_ Installation Hardware
X HLN6162_* Remote Hardware
X HLN6167_ Option Button Kit
X
X HSN6185_ Remote-Mount, SECURENET Control-Head Hardware
X HLN6344_ Interface Board
X HLN6481_* Systems 9000 E9 Clear Button Kit
X HLN6493_* Plug Kit
X HMN1061_ Microphone
X
HLN6127_ Dash Hardware, Low-Power Kit
X
HLN6459_ W3 Interface Board Kit
X
HMN4044_ ASTRO Handheld Control Head (W3)
X
HRN4010_ Low-Power RF Board Kit
X
TLN5277_ Filter Kit
X = Item Included
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
