Motorola ASTRO SPECTRA Service Manual

January 29, 2003 6881076C20-E
xxxiv Model Numbering, Charts, and Specifications
ASTRO Digital Spectra Plus 800 MHz Model Chart
Model Number Description
M04UGF9SW4AN Model W4 (800 MHz), 15 Watt, 128 Channels
M04UGF9SW5AN Model W5 (800 MHz), 15 Watt, 128 Channels
M04UGH9SW7AN Model W7 (800 MHz), 15 Watt, 512 Channels
D04UJH9SW3AN Model W3 (800 MHz), 35 Watt, 512 Channels
D04UJF9SW4AN Model W4 (800 MHz), 35 Watt, 128 Channels
D04UJF9SW5AN Model W5 (800 MHz), 35 Watt, 128 Channels
D04UJH9SW7AN Model W7 (800 MHz), 35 Watt, 512 Channels
T04UJH9SW9AN Model W9 (800 MHz), 35 Watt, 512 Channels
Item No. Description
X AAHN4045_ Front Housing, W4 Control Head
XXXX HKN4191_ Power Cable (Length-20 Feet)
XXXXX HLF6077_ Power Amplifier
X
XX HLF6078_ 15W. 800 MHz Power Amplifier
X
XXXXXXX HLF6079_ VCO Hybrid
X
XXXXXXX HLF6080_ VCO Carrier
XXXX HLN6015_ Trunnion/Hardware
X
XX X XXX HLN6688A_ Phon/Page/Emer/MPL Button
XXXXX HLN6126_ Mid-Power Dash Mount Radio Hardware
X
XX X XXX HLN6645A_ Emergency/MPL Field Option Button Kit
X HLN6549_* W4 Button Kit
X XX HLN6401_ Control Head Interconnect Board
X
XX HLN6365_ Interface Board, Motorcycle
X
XXXXXXX HLN6418_* Transceiver Hardware
X XX HMN1080_ Microphone, Modified Standard
X
XXXXXXX HRF6004_ Front-End Receiver Kit
X
XXXXXXX HRN6019_ RF Board Kit
XXXXX HSN4018_ Speaker
XXXXX RRA4914_ Antenna
XXXXX HLN5558_ Command Board Kit
X
XX HLN6562_ Command Board, Motorcycle
X X HLN6548_* SMARTNET Button Kit
XX HLN6396_ Control Head Deck Compatible
X HLN6440_* W5 Control Head without Keypad Hardware
X
PMLN4019_ W4 ASTRO Motorcycle Control Head
XX HLN6563_ Motorcycle Control Head
X HLN6445_* Hardware, Control Head, Motorcycle
X HLN6208_ Button, Spectra SECURENET
X HLN6441_* W7 Control Head with Keypad Hardware
X X HLN6523_* SMARTNET Button Kit
X HCN1078_ W9 Control Head
OOOOX HKN4192_ Power Cable (Length-20 Feet)
O OOX HKN4356_ Remote Mount Radio Cable (Length-17 Feet)
X HLN4921_ Trunnion, Control Head W9
X HLN4952_ Fuse Kit
X HLN5488_ Installation Hardware (W9 Trunnion)
X HLN6167_ Option Button Kit
XOOOX HLN6185_* Remote-Mount, SECURENET Control Head Hardware
O OOX HLN6344_ Interface Board, Remote Mount
X HLN6481_* Systems 9000 E9 Clear Button Kit
X HMN1061_ Microphone
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
