11-10 Exploded Views and Parts Lists: Small Pushbutton Parts
February 3, 2003 6881076C20-E
11.10 Small Pushbutton Parts 11.11 Large Pushbutton Parts
Table 11-10. Small Pushbutton Parts List
Part Number
Graphic
Legend
Part Number
Graphic
Legend
3805671X02 1 3805671X21 9wxy
3805671X03 2 3805671X22 * Rcl
3805671X04 3 3805671X23 #Del
3805671X05 4 3805671X24 1Ste
3805671X06 5 3805671X25 2Pge
3805671X07 6 3805671X26 3Lck
3805671X08 7 3805671X27 4Sts
3805671X09 8 3805671X28 5Rpg
3805671X10 9 3805671X29 6Msg
3805671X11 0 3805671X30 7H/L
3805671X12 * 3805671X31 8Mon
3805671X13 # 3805671X32 9Dir
3805671X14 2abc 3805671X33 Mon
3805671X15 3def 3805671X34 H/L
3805671X16 4ghi 3805671X35 DIR
3805671X17 5jkl 3805671X36 Urg
3805671X18 6mno 3805671X37 RTT
3805671X19 7prs 3805671X38 Home
3805671X20 8tuv 3805671X39 Dim
Table 11-11. Large Pushbutton Parts List
Part Number
Graphic
Legend
Part Number
Graphic
Legend
3805672X01 - - 3805672X10 H/L
3805672X02 MPL 3805672X11 Sts
3805672X03 Scan 3805672X12 Call
3805672X04 DVP 3805672X13 Msg
3805672X05 PA 3805672X14 Rcl
3805672X06 Sirn 3805672X15 Mode
3805672X07 Wail 3805672X16 ExRd
3805672X08 Hi/Lo 3805672X17 Del
3805672X09 Man 3805672X18 Sel
3805672X19 Mon 3805672X52 Emer
3805672X20 DTMF 3805672X53 Stdy
3805672X21 Yelp 3805672X54 ECC
3805672X22 MVS 3805672X55 Rptr
3805672X23 Play 3805672X56 State
3805672X24 Rply 3805672X57 Reg
3805672X25 Rcrd 3805672X58 AirHn
3805672X26 Emer 3805672X59 TB Scn
3805672X27 Ext 3805672X60 SCC
3805672X28 F/R 3805672X61 Srch
3805672X29 Alt 3805672X62 Lock
3805672X30 Tel 3805672X63 Page
3805672X31 Sql 3805672X64 Rear
3805672X32 DES 3805672X65 Xfer
3805672X33 Txt 3805672X66 ST
3805672X34 Indv 3805672X67 VHF
3805672X35 Pvt 3805672X68 UHF
3805672X36 Site 3805672X69 Aux
3805672X37 AA 3805672X70 QC II
3805672X38 Sub 3805672X71 Mute
3805672X39 Home 3805672X72 Pri
3805672X40 Menu 3805672X73 Blu
3805672X41 Rpgm 3805672X74 Div
3805672X42 Step 3805672X75 RTT
3805672X43 3805672X76 Send
3805672X44 Phon 3805672X77 Front
3805672X45 Dir 3805672X78 Bid
3805672X46 Text 3805672X79 ZONE
3805672X47 Rvw 3805672X80 TRBL
3805672X48 Sec 3805672X81 OVHD
3805672X49 Ø 3805672X82 UNGD
3805672X50 L/S 3805672X83 RSSI
3805672X51 S/S 3805672X84 VRS
3805672X85 A/B 3805669X12 ETrp
3805672X86 Chan 3805669X13 LvTe
3805672X87 PRTT 3805669X14 ArTe
3805672X88 RtRn 3805669X15 LvGg
3805672X89 Emp# 3805669X16 ArGg
3805672X90 Pass 3805669X17 P/in
3805672X91 Cir 3805669X18 P/out
3805672X92 URG 3805669X19 Serv
3805672X93 A 3805669X20 0/S
3805672X94 B 3805669X21 Rev
3805672X95 C 3805669X22 Stby
3805672X96 D 3805669X23 Sts 1
3805672X97 E 3805669X24 Sts 2
3805672X98 F 3805669X25 Sts 3
3805672X99 G 3805669X26 Sts 4
3805669X01 K 3805669X27 Sts 5
3805669X02 L 3805669X28 Sts 6
3805669X03 T/Z 3805669X29 Sts 7
3805669X04 30 3805669X30 Sts 8
Table 11-11. Large Pushbutton Parts List (Continued)
Part Number
Graphic
Legend
Part Number
Graphic
Legend
3805669X05 Entr 3805669X31 Drvr
3805669X06 M/WT 3805669X32 Bdg#
3805669X07 MAck 3805669X33 LnBI
3805669X08 Time 3805669X34 RtBl
3805669X09 SRun 3805669X35 LnRn
3805669X10 ERun 3805669X36 s
3805669X11 STrp 3805669X37 t
Table 11-11. Large Pushbutton Parts List (Continued)
Part Number
Graphic
Legend
Part Number
Graphic
Legend
