xxxii Model Numbering, Charts, and Specifications
ASTRO Digital Spectra Plus UHF 50–110 Watt Model Chart
Model Number Description
T04QLH9SW3AN Model W3 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLF9SW4AN Model W4 (403-433 MHz), 50-110 Watt, 128 Channels
T04QLF9SW5AN Model W5 (403-433 MHz), 50-110 Watt, 128 Channels
T04QLH9SW7AN Model W7 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLH9SW9AN Model W9 (403-433 MHz), 50-110 Watt, 512 Channels
T04RLH9SW3AN Model W3 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLF9SW4AN Model W4 (450-482 MHz), 50-110 Watt, 128 Channels
T04RLF9SW5AN Model W5 (450-482 MHz), 50-110 Watt, 128 Channels
T04RLH9SW7AN Model W7 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLH9SW9AN Model W9 (450-482 MHz), 50-110 Watt, 512 Channels
T04SLH9SW3AN Model W3 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLF9SW4AN Model W4 (482-512 MHz), 50-110 Watt, 128 Channels
T04SLF9SW5AN Model W5 (482-512 MHz), 50-110 Watt, 128 Channels
T04SLH9SW7AN Model W7 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLH9SW9AN Model W9 (482-512 MHz), 50-110 Watt, 512 Channels
Item No. Description
X X X AAHN4045_ Control Head Assembly (W4)
XX
XXX HAE4002_ Antenna, Roof Top
XXXXX HAE4003_ Antenna, Quarterwave
X XXXX HAE4004_ Antenna, Roof Top
X X X HCN1078_ W9 Control Head
XX
XXXXXXXXXXXXX HKN4051_ Cable and Fuse
X
XXX XXXX XXXX HKN4356_ Radio Cable (Length-17 Feet)
XX
XXXXXXXXXXXXX HKN6039_ Power Cable (Length-17 Feet)
X
X X HKN6096_ Handheld Control Head “Y” Cable Kit
XXXXX HLE6039_ VCO Carrier, Range 3
X XXXX HLE6040_ Power Amplifier Board, Range 4
X XXXX HLE6041_ VCO Carrier, Range 4
XX
XXX HLE6045_ VCO Carrier, Range 1
XX
XXX HLE6051_ Power Amplifier Board, 100W, Range 1
XX
XXX HLE6101_ VCO Hybrid Kit, Range 1
XXXXX HLE6103_ VCO Hybrid Kit, Range 3
X XXXX HLE6104_ VCO Hybrid Kit, Range 4
X X X HLN4921_ Trunnion
X
XXX XXXX XXXX HLN4952_ Fuse Kit
XX
XXXXXXXXXXXXX HLN5558_ Command Board Kit
X
X X HLN6105_ Emergency/Secure/MPL Button Kit
XX
XXXXXXXXXXXXX HLN6121_* High-Power Radio Hardware
XX
XXXXXXXXXXXXX HLN6132_* Installation Hardware, High-Power
X X X HLN6167_ Option Button Kit
X
XX XXX XXX HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
XX
XXXXXXXXXXXXX HLN6233_* Option Connector Hardware
X
X X HLN6291_ Installation Hardware Kit
XX X X XX HLN6396_ W5, W7 Control Head Board
X
XX XXX XXX HLN6432_ Back Housing, Control Head
X X X HLN6440_* Control Head without Keypad Hardware
X X X HLN6441_* Control Head with Keypad Hardware
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
