4-4 Test Equipment, Service Aids, and Tools: Service Aids and Recommended Tools
Table 4-5 lists additional service aids that can be used in troubleshooting ASTRO Digital Spectra
radios.
Table 4-6 lists additional service aids that can be used in troubleshooting ASTRO Digital Spectra
Plus radios.
Table 4-5. Service Aids for ASTRO Digital Spectra Board-Level Troubleshooting
Motorola
Part Number
Description Application
RLN-4008_ Radio Interface Box (RIB) Enables communications between the radio and the
RSS
RLN-1015_ Smart RIB (SRIB) Enables communications between the radio and the
RSS. Required to FLASH the radio
RLN-4488_ Battery Pack Used to supply backup power to SRIB
01-80357A57 Wall-Mounted Power Supply Used to supply power to the RIB (120 Vac)
01-80358A56 Wall-Mounted Power Supply Used to supply power to the RIB (220 Vac)
01-80302E27 Adapter Used to supply power to the SRIB (120 Vac)
25-80373E86 Adapter Used to supply power to the SRIB (220 Vac)
30-80369B71 (25-pin to
15-pin) or
30-80369B72 (9-pin to
15-pin)
Computer Interface Cable Connects the computer’s serial communications
adaptor to the RIB
30-80390B48 (9-pin to
9-pin) or
30-80390B49 (25-pin to
9-pin)
Computer Interface Cable Connects the computer’s serial communications
adaptor to the SRIB
30-80369B73 or
01-80300B10
Radio Interface Cable Connects low-power and mid-power radios to the RIB
Radio Interface Cable Connects high-power radios to the RIB
RVN-4184 Radio Service Software
(DOS Version)
Replaces RVN-4124. Software on 3-1/2 in. and 5-1/4 in.
floppy disks
RVN-4183 Customer Programming
Software (Windows Version)
Programming software; available only on CD.
