xxviii Model Numbering, Charts, and Specifications
ASTRO Digital Spectra Plus VHF 25–50 and 50–110 Watt Model Chart
Model Number Description
D04JKH9SW7AN Model W7 (136-162 MHz), 25-50 Watt, 512 Channels
D04KKH9SW3AN Model W3 (146-174 MHz), 25-50 Watt, 512 Channels
D04KKF9SW4AN Model W4 (146-174 MHz), 25-50 Watt, 512 Channels
D04KKF9SW5AN Model W5 (146-174 MHz); 25-50 Watt, 512 Channels
D04KKH9SW7AN Model W7 (146-174 MHz), 25-50 Watt, 512 Channels
T04KKH9SW9AN Model W9 (146-174 MHz), 25-50 Watt, 512 Channels
T04KLH9SW3AN Model W3 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLF9SW4AN Model W4 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLF9SW5AN Model W5 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLH9SW7AN Model W7 (146-174 MHz), 50-110 Watt, 512 Channels
T04KLH9SW9AN Model W9 (146-174 MHz), 50-110 Watt, 512 Channels
Item No. Description
X HRD6001_ Front-End Rcvr Board Kit (Range 1, 136-162 MHz)
X XXXXXXXXX HRD6002_ Front-End Rcvr Board Kit (Range 2, 146-174 MHz)
XXXXXXXXXXX HRN6014_ RF Board Kit
XXXXXXXXXXX HLD4342_ VCO Board Kit
X HLD6061_ VCO Hybrid Kit (Range 1, 136-162 MHz)
X XXXXXXXXX HLD6062_ VCO Hybrid Kit (Range 2, 146-174 MHz)
XXXXXXXXXXX HLN5558_ Command Board Kit
XXXXXXXXXXX HLN6837_ VOCON Board Kit
XXXXXX HLD6022_ Power Amplifier Board (25-50W, Range 2, 146-174 MHz)
XXXXX HLD6063_ Power Amplifier Board (50-110W, Range 2, 146-174 MHz)
X HLN6344_ Interface Board
X XXX HLN6401_ Control Head Interconnect Board
X X AAHN4045_ W4 Control Head
X XXX HLN6486_ High-Power Interconnect Board
X XX HLN6432_ Control Head Back Housing
X X X XX HLN6396_ W5,W7 Control Head Board
X X HCN1078_ W9 Control Head
OOOOOOOOOOO NTN9801_ ASTRO Spectra Plus UCM
XXX X XX HMN1080_ Microphone
X X HMN1061_ Microphone
XXXXXX HSN4018_ Speaker
XXXXX HSN6001_ Speaker
X X HLN4921_ Control Head (W9) Trunnion
X X HLN5488_ Radio Microphone Installation Hardware (W9 Trunnion)
X X HLN6185_* Remote-Mount, SECURENET Control-Head Hardware
X XX HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
XXXXX HLN6233_* Option Connector Hardware
XXXXX HLN6132_* High-Power Installation Hardware
XXXXX HLN6015_ Trunnion/Hardware (Dash Mount)
XXXXX HLN6060_ Dash-Mount Hardware
XXXXX HLN6121_* High-Power Radio Hardware
XXXXXX HLN6866_* Transceiver Hardware
X X HLN6440_* Control Head without Keypad Hardware
X X X HLN6441_* Control Head with Keypad Hardware
XXXXX HLN6525_* High-Power Transceiver Hardware
X X HLN6493_* Plug Kit
X X XXX HLN4952_ Fuse Kit
X X XXX HKN4356_ Radio Cable (Length -17 Feet)
X = Item Included
O = Optional item
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
