Operating job computer on the field
Controlling the boom
3. - Open the ball valve.
⇨ The icon will appear.
⇨ Filling starts.
⇨ When the fill level defined as refilling limit 1 is reached, the ball valve closes and filling is
terminated.
⇨ If there is a second refilling limit, it will be automatically activated.
4. You can now add the spray agent and stir the tank contents.
5. Prepare the field sprayer for the second filling.
6. - Open the ball valve.
⇨ Filling starts.
⇨ When the fill level defined as refilling limit 2 is reached, the ball valve closes and filling is
terminated.
Controlling the boom
In this section you learn how to control the boom using the terminal.
Injury to persons through improper operation
Every field sprayer is designed differently and must be operated differently. In this section, only the
icons that appear on the screen of the terminal can be explained.
◦ Read the field sprayer operating guide.
◦ Learn the sequence in which your field sprayer must be operated safely.
Lifting and lowering the boom
This is how you reach the screen with this function:
To operate this function the user needs the ME joystick first of all.
Use the following function keys to operate the function:
Activates and deactivates DISTANCE-Control.
On the following diagram you see how this function is shown on the work screen:
