Configuring the job computer
Selecting and configuring the speed sensor
⇨ The current flow appears on the "Measured flow" line.
4. - Start application.
5. Go to one of the nozzles and carefully collect the water sprayed for 60 seconds by using the
prepared measuring cup.
6. Write down the applied water volume.
7. Repeat the last two steps on several nozzles.
8. Calculate and write down an average of several measurements.
9. - Stop application.
⇨ The application will be stopped.
10. - Stop calibration.
⇨ An input box appears on the "3. Enter real volume per nozzle " line.
11. Enter the average applied volume in litres in this box.
12. - Exit screen.
⇨ The value of the "Pulses main flow" parameter will be updated.
⇨ You have calibrated the flow meter with the nozzle method.
Manually entering the number of pulses per liter for the flow meter
If you know the precise number of pulses per liter for the flow meter, you can enter this value
manually.
1. Switch to the "CALIBRATION" screen:
> >
2. Enter number of pulses per litre on the "Pulses main flow" line.
Selecting and configuring the speed sensor
You must enter the source from which the job computer shall obtain the current speed.
The configuration process can differ depending on the speed source.
Selecting the speed source
Supported speed sources:
▪ "Sensor" – Sensors that are installed on the field sprayer and connected to the job computer:
– Examples: Wheel sensor, radar sensor, impulse-transmitting GPS speed sensor
– Configuration: Configure the number of impulses per 100 meters.
▪ "ISOBUS" – Sensors that are installed on the tractor and whose signal is received through the
ISOBUS.
– Examples: GPS receiver, wheel sensor on the tractor, signal socket
