TRAIL-Control
Configuring TRAIL-Control
Phase 2: Recording the limit stops
1. - Steer the trailed implement fully to the left.
2. - Start the calibration.
⇨ The following message appears:
"Most left position: Calibration is ready"
3. - Confirm within 3 seconds. The time will be counted by a red clock:
⇨ Calibration is initiated.
⇨ The following message appears:
"Most left position: Calibration running"
⇨ A blue clock shows the progress:
4. Wait until the message "Most left position: Calibration running" is no longer displayed.
5. - Steer the trailed implement fully to the right.
6. - Start the calibration.
⇨ The following message appears:
"Most right position: Calibration is ready"
7. - Confirm within 3 seconds. The time will be counted by a red clock:
⇨ Calibration is initiated.
⇨ The following message appears:
"Most right position: Calibration running"
⇨ A blue clock shows the progress:
8. Wait until the message "Most right position: Calibration running" is no longer displayed.
⇨ Phase 2 of calibration has been completed.
Calibrating the hydraulics of the proportional valve
You must only calibrate the hydraulics of the proportional valve when you use a trailed implement
with proportional valve.
Danger of injury from trailed implement movement
When calibrating the proportional valve, the trailed implement moves automatically.
This may pose a risk to you and to persons in the immediate vicinity of the trailed implement.
◦ Ensure that nobody is in the regulation range of the trailed implement.
◦ Abort the calibration with the or function key as soon as someone
approaches the trailed implement.
TRAIL-Control is in manual mode.
