Configuring the job computer
Entering field sprayer parameters
You have to configure the following
Section with more information
Collaboration with the terminal
Configuring the communication with the terminal
(Condensed Work State) [➙ 57]
Calibrating the flow meter
Calibrating the flow meter [➙ 58]
Configuring the speed sensor
Selecting and configuring the speed sensor [➙
62]
Configuring sections [➙ 65]
Entering field sprayer parameters
Enter the parameters in the following cases:
▪ Prior to initial start-up.
▪ When the field sprayer parameters change.
To change the value of a parameter:
1. Switch to the "Parameters" screen:
⇨ The "Parameters" screen appears.
⇨ A small rectangular box with a value appears under each parameter.
2. Select this box to change a parameter.
⇨ Screen for data input or keyboard appears.
3. Enter desired value.
⇨ The new value appears on the "Parameters" screen.
The list contains all parameters that can appear on the screen. The parameters appearing on your
screen depend on the type and configuration of your field sprayer.
Nozzle
Colour of the activated nozzles.
The colours are specified by the ISO standard. The nozzles can also be calibrated. [➙ 67]
This parameter only appears on systems that do not have a flow meter. With these systems, a
pressure sensor for determining the application rate is used instead.
Rate
The quantity entered as the target rate will be applied when the field sprayer is working in automatic
mode.
Working width
Field sprayer working width.
