TRAIL-Control
TRAIL-Control – Using drawbar and stub axle steering
2. - Activate or deactivate function:
⇨ On the screen, you can see whether the function is activated:
- Function enabled
- Function disabled.
Using slope counter-steering in automatic mode
When you work in automatic mode, the trailed implement is steered automatically.
To steer against the slope in automatic mode:
The trailed implement is equipped with a slope sensor.
During the calibration of TRAIL-Control, the slope sensor was mounted on the frame of the
sprayer. The sensor position has not changed since.
Automatic mode is activated.
"Slope countersteer" function is activated.
The vehicle with the trailed implement is moving on the slope.
1. , or , - Manually steer the trailed implement to the correct
position behind the tractor.
⇨ The work screen displays the icon . The red colour marks the target position of the
angle sensor on the drawbar.
⇨ Each time you press a function icon, the triangle becomes more or less red in colour.
⇨ TRAIL-Control will try to steer the trailed implement into this position, until you correct the
position manually again.
2. After turning, when the slope lies on the other side of the trailed implement, the angle will be
reproduced on the other side.
Using slope counter-steering in manual mode
In manual mode, you must steer the trailed implement manually against the slope. Here, you can
decide yourself whether the trailed implement should follow the track of the tractor or whether it
should be offset.
Preparing TRAIL-Control for road driving
Before driving with the field sprayer on a public road, you must switch TRAIL-Control off and if
possible lock it with a locking pin.
