Configuring the job computer
Configuring the control units
Configuring the job computer
Configuring the control units
The joystick and S-Box control units are configured on a screen.
▪ "Joystick" parameter:
– "Without Joystick": Joystick is not connected. All functions will be controlled using the
terminal or an ME S-Box.
– "ME Joystick": ME Joystick will be used.
– "Ignore ME Joystick": The joystick should be ignored. Setting for the auxiliary job computer
for systems with two job computers.
– "ME-Joyst. only On/Off": Setting for the auxiliary job computer, if on/off (section main switch)
is deactivated on the S-Box.
▪ "ME S-Box" parameter:
– "Without ME S-Box" No S-Box connected.
– "ME S-Box": Default setting when the S-Box is available.
– "Ignore ME S-Box": For systems with two job computers, this is the setting for the first job
computer. The signals from the ME S-Box are rejected because this job computer should be
operated with the joystick.
– "ME SBox without On/Off": Setting for the second job computer.
▪ "Joystick assistant" parameter:
– - Preview mode deactivated
– - Preview mode [➙ 47] activated Beside this, you can set the display time for the
button assignment.
1. Switch to the "Parameters" screen:
> > > >
⇨ The "AUX controls" screen appears.
2. Configure parameter.
Overview of the configuration steps
The following table contains the most important configuration steps that must be performed during
initial start-up. If your system includes additional components, such as TRAIL-Control, DISTANCE-
Control, AIRTEC, TANK-Control etc., these must also be configured and calibrated.
You have to configure the following
Section with more information
Entering field sprayer parameters [➙ 54]
Entering the field sprayer geometry [➙ 81]
Configuring external operating devices
Configuring the control units [➙ 53]
