Operating job computer on the field
Starting application
You have calibrated the boom potentiometer (slope angle sensor). [➙ 82]
1. Drive across the slope gradient with the field sprayer.
2. Position the boom parallel to the sloped ground.
3. – Press on the headlands before the turning manoeuvre.
⇨ The current angle will be saved.
⇨ - Two white arrows pointing down appear.
⇨ The system returns the boom to the horizontal position.
⇨ While the boom is moving, a green arrow appears on the work screen.
⇨ When the boom is horizontal, the icon appears.
4. Turn only when the boom is horizontal.
5. - Press once after the turning manoeuvre.
⇨ The job computer slopes the boom in the opposite direction until the previously saved angle
is reached on the other side.
⇨ While the boom is moving, a green arrow appears on the work screen.
⇨ The function switches off if you change the boom angle manually.
Starting application
To start the application:
The tractor with the field sprayer is on the field.
You have configured the job computer.
You have folded out the boom.
1. Ensure that all prerequisites have been fulfilled.
2. - Start application.
⇨ In manual mode:
The field sprayer starts the application.
Spray cones appear under the boom icon:
⇨ In automatic mode:
The field sprayer will be prepared for application.
As long as the field sprayer does not move, the following icon appears in the work screen:
3. In automatic mode:
Start driving and exceed the minimum speed for the automatic regulation (parameter:
"Regulation off below").
