SECTION 4 -- LUBRICATION AND MAINTENANCE
4--29
OPERATION 15
CHECK TRANSMISSION/REAR AXLE
AND HYDRAULIC OIL LEVEL
Check the oil level with the tractor parked on a lelvel
surface, with all cylinders extended and the engine
shut off for at least five minutes.
Check the oil level in the sight glass on the left hand
side of the rear axle housing. Ensure that the the oil
level is between the high and low marks, in the sight
glass.
58
If necessary , remove the filler cap and add oil , as
required.
See page 4--9 for the correct oil specification.
IMPORTANT: Park the tractor on level ground and,
where applicable, extend all cylinders before
checking oil levels. With some front/rear wheel
combinations, it may be necessary to raise the front
or rear of the tractor to ensure it is level before
checking the oil.
