PROGRAMMING THE CONTROL UNIT
8
8 PROGRAMMING THE CONTROL UNIT
There are 3 buttons on the control unit:
f
,
g
and
h
(“Figure 42”) which can be used both to command the control
unit and to programme the available functions.
Aerial
42
The available programmable functions are grouped into two levels and
their operating status is signalled by eight LEDs “L1 ... L8” located on the
control unit (LED lit = function enabled; LED off = function disabled).
8.1 USING THE PROGRAMMING BUTTONS
f
The button allows for commanding the door opening movement, or shift-
ing the programming point upwards.
g
Button used to stop a manoeuvre.
If pressed for more than 3 seconds, it allows for entering the programming
mode.
h
The button enables the user to close the door or shift the programming
point downwards.
a
Warning! During the manoeuvre, whether opening or
closing is irrelevant, all the buttons perform the STOP
function and stop the motor’s movement.
