Nice SPIDER Series User Manual

ENGLISH – 59
TECHNICAL SPECIFICATIONS
16
16 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A. reserves the
right to apply modications to the product at any time when deemed necessary, without altering its functions and intended
use.
Table 39
GEARMOTOR TECHNICAL SPECIFICATIONS
Description SPIDER800 SPIDER1200BL
Product type
Electromechanical gearmotor for the automatic movement
of garage doors for residential use, inclusive of electronic
control unit
Electromechanical gearmotor for the automatic movement
of garage doors for residential use, inclusive of electronic
control unit
Power supply
230Va (+/-10%) 50/60Hz 230Va (+/-10%) 50/60Hz
Power supply /V1
120Va (+/-10%) 50/60Hz 120Va (+/-10%) 50/60Hz
Maximum torque
(corresponding to the
maximum force)
14.4 Nm (800 N) 21.6 Nm (1200N)
Maximum force 800 N 1200 N
Nominal force 400 N 600 N
Power in stand-by mode
(W)
< 1 < 1
Maximum power
consumption (W)
280 350
Nominal power
consumption (W)
180 240
Maximum speed (m/s) 0,20 0,16
Protection rating (IP) 40 40
Operating temperature
(min/max °C)
-20°C ... +55°C -20°C ... +55°C
Insulation class I I
Maximum no. of cycles/day 50 150
Maximum continuous
operating time
4 minutes 4 minutes
Dimensions (mm) 225x395x105 225x395x105
Weight (kg) 4,9 6,7
Emergency power supply With optional accessory PS124 With optional accessory PS124
Courtesy light Integrated with LED Integrated with LED
FLASH output [Note 1] Output for connecting the warning light (max 10 W) Output for connecting the warning light (max 10 W)
OGI output [Note 1] Output for connecting the Open Gate Indicator (max 10 W) Output for connecting the Open Gate Indicator (max 10 W)
STOP input
For normally closed or normally open contacts, 8.2 KΩ xed
resistor contacts or OSE optical devices with self-learning
function (any variation from the memorised status triggers
the “STOP” command)
For normally closed or normally open contacts, 8.2 KΩ xed
resistor contacts or OSE optical devices with self-learning
function (any variation from the memorised status triggers
the “STOP” command)
SbS input
For normally open contacts (closing of the contact triggers
the STEP-BY-STEP command)
For normally open contacts (closing of the contact triggers
the STEP-BY-STEP command)
PHOTO input
For normally closed contacts (the contact’s opening triggers
the photocell reopening command)
For normally closed contacts (the contact’s opening triggers
the photocell reopening command)
Radio ANTENNA input 52 Ω for RG58-type cable or similar 52 Ω for RG58-type cable or similar
Programming input For accessories compatible with the IBT4N interface For accessories compatible with the IBT4N interface
Programmable functions 8 type ON-OFF functions and 8 adjustable functions 8 type ON-OFF functions and 8 adjustable functions
Self-learning functions
Self-learning of the type of “STOP” device (Normally Open,
Normally Closed contact or 8.2 kΩ resistor, optical sensitive
edge)
Expansion board and calculation of the slowdown and partial
opening points
Self-learning of the type of “STOP” device (Normally Open,
Normally Closed contact or 8.2 kΩ resistor, optical sensitive
edge)
Expansion board and calculation of the slowdown and partial
opening points
Use in highly acid, saline
or potentially explosive
atmosphere
No No
Note 1 The output can be programmed with other functions (see “Table 20” on page 28 29) or through the Oview programmer.
