ENGLISH – 55
INPUT CONFIGURATION
14
14 INPUT CONFIGURATION
This item groups the available congurations that can be associated with the inputs present on the control unit and on expansion boards, if any (optional
accessories).
The inputs present on the control unit’s terminal block are identied as:
– INPUT 1 (0x71) (Default = Step-by-Step)
– INPUT 2 (0x72) (Default = Photo)
The inputs available on the expansion boards are identied as:
– INPUT 3 (0x73) (where available) (Default = Open)
– INPUT 4 (0x74) (where available) (Default = Close)
– INPUT 5 (0x7C) (where available) (Default = Partial open 1)
– INPUT 6 (0x7D) (where available) (Default = Emergency Open)
l
In addition to the basic and extended commands described in the “Basic parameters” and “Extended commands” para-
graphs, the functions indicated in the table below are included for the terminal block inputs
Table 36
INPUT CONFIGURATION
FUNCTION DESCRIPTION
(input managed as NC)
The control unit manages the input as a safety device interpreting its switching as an intervention of the “PHOTO” photocell.
Photo 1
(input managed as NC)
The control unit manages the input as a safety device interpreting its switching as an intervention of the “PHOTO1”
photocell.
Photo 2
(input managed as NC)
The control unit manages the input as a safety device interpreting its switching as an intervention of the “PHOTO2”
photocell.
Photo 3
(input managed as NC)
The control unit manages the input as a safety device interpreting its switching as an intervention of the “PHOTO3”
photocell.
Opening on Emergency
(input managed as NC)
The control unit forces an opening command when the input opens. No command can interrupt the manoeuvre started by
the emergency input and only the intervention of a safety device (photocells or STOP input) can suspend the request.
Warning = If a safety device intervenes, the control unit will attempt the manoeuvre several times. In case of repeated
interventions, the manoeuvre will be suspended.
Closing on Emergency
(input managed as NC)
The control unit forces a closing command when the input opens. No command can interrupt the manoeuvre started by the
emergency input and only the intervention of a safety device (photocells or STOP input) can suspend the request.
Warning = If a safety device intervenes, the control unit will attempt the manoeuvre several times. In case of repeated
interventions, the manoeuvre will be suspended.
a
Important – To ensure that the control unit works properly, each input must be associated with a command or function and
then with the desired operating mode according to “Control mode description”. All the parameters are pre-set in the factory
but can be modied as required.
