ENGLISH – 45

11.3 INSTALLATION PARAMETERS

BlueBus search (0x0A)

This function can be used to start the learning procedure for devices connected to the BlueBus input and to the STOP input. It is also used to identify

the direction of rotation of the motor (refer to the paragraph concerning the motor’s rotation direction) and associate the connected expansion boards.

Position programming

a

After any change made to the following parameters, the control unit must restart the Automatic Force Search procedure

(refer to the “Automatic force search” paragraph).

– Cruising speed (30

100 (%), default = 50 (%))

Allows for dening the speed to be used during the position programming procedure.

– Opening

65535, default = 65535)

Allows for programming the desired maximum opening position

– Opening slowdown

65535, default = 65535)

Allows for programming the opening slowdown position: near this value the automation starts decelerating before reaching the maximum opening

position.

– Partial opening

65535, default = 65535)

Allows for programming the desired maximum opening position.

– Closing slowdown

65535, default = 65535)

Allows for programming the closing slowdown position: near this value the automation starts decelerating before reaching the maximum closing position.

– Closing

65535, default = 65535)

Allows for programming the maximum closing position which must necessarily hit the ground.

– Exclusion position

65535, default = 50)

Allows for programming the position within which the automation ignores any obstacle detection intervention.

– Photo exclusion position

65535, default = 0)

Allows for programming the position within which the automation ignores any photocell detection intervention.

– Open discharge (0

200, default = 0)

Allows for programming the reversal space (in terms of the path along the guide) on closing after the opening position has been reached. This allows for

slowing down the mechanical pressure exerted on the automation.

– Close discharge (0

200, default: SPIDER800 = 25, SPIDER1200BL = 75)

Allows for programming the reversal space (in terms of the path along the guide) on opening after the maximum closing position has been reached. This

allows for slowing down the mechanical pressure exerted on the automation.
