3 - 83
3 Specifications
OMNUC G5-series (Pulse-train Input Type) A
C Ser
vomotor
s and Servo Drives User’
s Manual
3-5 Cable and Connector Specifications
3
3-5-5 Analog Monitor Cable Specifications

Connection configuration
and external dimensions
3-5-5
Analog Monitor Cable Specifications
Analog Monitor Cable (R88A-CMK001S)
No.
1
2
3
4
5
6
AM1
AM2
GND
51004-0600 (Molex Japan)
50011-8000 (Molex Japan)
Symbol
White
Red
Black
Cable: AWG24 x 3C UL1007
Connector housing:
Connector terminal:
1 m
182
184
