3 Specifications
3 - 124
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
3-8 Reactor Specifications
Connect a Reactor to the Servo Drive for reduction of harmonic current. Select an appropriate Reactor
according to the Servo Drive model.
Specifications
Servo Drive model
Reactor
Model
Rated
current
Inductance Weight
Reactor
type
R88D-KP01H (For single-phase input) 3G3AX-DL2002 1.6 A 21.4 mH Approx.
0.8 kg
DC
reactor
R88D-KP02H (For single-phase input) 3G3AX-DL2004 3.2 A 10.7 mH Approx.
1.0 kg
R88D-KP04H (For single-phase input) 3G3AX-DL2007 6.1 A 6.75 mH Approx.
1.3 kg
R88D-KP08H
R88D-KP10H (For single-phase input)
3G3AX-DL2015 9.3 A 3.51 mH Approx.
1.6 kg
R88D-KP15H (For single-phase input) 3G3AX-DL2022 13.8 A 2.51 mH Approx.
2.1 kg
R88D-KP01H
R88D-KP02H
R88D-KP04H
R88D-KP08H
R88D-KP10H
R88D-KP15H (For 3-phase input)
3G3AX-AL2025 10.0 A 2.8 mH Approx.
2.8 kg
AC
reactor
R88D-KP20H
R88D-KP30H
3G3AX-AL2055 20.0 A 0.88 mH Approx.
4.0 kg
R88D-KP50H 3G3AX-AL2110 34.0 A 0.35 mH Approx.
5.0 kg
