Omron LD User Manual

LD Cart Transporter User's Guide, 14766-000 Rev B
Page 143 of 190
Chapter 10: Maintenance
This chapter covers periodic maintenance and user-serviceable parts replacement for the LD
Cart Transporter.
Navigation
Laser
Low
Front
Laser
Light
Disc x2
Rear
Sonar
Battery
Cover
Side Laser, Guard x2
Laser Support
Tube x2
Brace x2
HMI
Post
Rear-facing
Laser, Guard
Operator
Panel
Figure 10-1. Major LD Cart Transporter System Parts, with Acuity Camera
Coupling
Laser Cover
Cart Latch
Top Plate
HMI Post Base
HMI Post
Operator Panel
Rear-facing Laser
Touchscreen
E-Stop, LATCH, UNLATCH
Light Pole (Beacon)
ON/OFF/BRAKE/Key Switch
Antenna x2
Latch
Position
Sensor
Latching Mechanism Cover
Figure 10-2. Top View of an LD Cart Transporter, Side Laser Support Tubes Removed
