LD Cart Transporter User's Guide, 14766-000 Rev B
Page 153 of 190
Chapter 10: Maintenance
Removing Top Plate
1.
Remove the two stainless M5 screws that were covered by the Latching Mechanism
cover.
Retain the M5 screws for reassembly. These are socket-head cap screws.
2.
Remove the eight M6 screws along the sides and front of the top plate.
Retain the M6 screws for reassembly. These are flat head, stainless screws.
3.
Disconnect the cables going to the latching assembly and sensors in the Latching Mech-
anism.
4.
Carefully lift off the top plate.
As you remove the top plate:
CAUTION: Take care not to scratch the laser lens when removing the
top plate.
At this point, you will have access to the payload bay.
Installing Top Plate
1.
Resintall the top plate.
CAUTION: Take care not to scratch the laser lens when reinstalling the
top plate.
2.
Reconnect the cabling to the latching motor assembly and its sensors.
3.
Reinstall the eight M6 screws along the sides and front of the top plate.
Use the screws previously removed from the top plate.
4.
Reinstall the two M5 screws that were covered by the Latching Mechanism cover.
Use the screws previously removed from the top plate.
Installing Latching Mechanism Cover
1.
Place the Latching Mechanism cover back onto the top plate.
2.
Reinstall the four M3 screws holding the Latching Mechanism cover to the top plate.
Use the screws previously removed from the Latching Mechanism cover.
These go into four 45 mm standoffs in the top plate.
