Omron LD User Manual

LD Cart Transporter User's Guide, 14766-000 Rev B
Page 183 of 190
Chapter 11: Technical Specifications
11.1 Dimension Drawings
Ø101.6
(4.0)
497.8 (19.6)
429
(16.9)
132
(5.2)
1391.9
(54.8)
624.8
(24.6)
6.3
(160)
49.3
(1.94)
1305.6
(51.4)
696 (27.4)
894 (35.2)
195.6 (7.7)
86.4 (3.4)
94
(3.7)
497.8 (19.6)
61
(2.4)
416.6
(16.4)
Units are mm (in.)
61
(2.4)
Figure 11-1. Overall LD Cart Transporter Dimensions
Units are mm (in.)
10x Ø 6.6 (0.26) THRU
0
41.9 (1.65)
188 (7.40)
334 (13.15)
479.8 (18.89)
502.7 (19.79)
24.1 (0.95)
429
(16.89)
453
(17.83)
153.4
(6.04)
299.5
(11.79)
0
Figure 11-2. Coupling Plate Dimensions, Arms Removed
