LD Cart Transporter User's Guide, 14766-000 Rev B
Page 147 of 190
Chapter 10: Maintenance
10.3 Safety Inspection
Item Period Reference
Warning Devices 1 week Warning Devices on page 147
Warning Labels 1 week Warning Labels on page 147
Informative Labels 1 week Informative Labels on page 149
Warning Devices
The following warning devices should be inspected for proper function on a weekly basis.
Light Discs
The light discs on each side of the transporter should be checked.
Flashing Light(s)
The beacon on top of the HMI post should be checked.
If there is a user-installed beacon or light tower that has been installed to warn people of the
AIV’s movement or imminent movement, it should be checked for proper function every week.
You should ensure that the light remains visible under all operating conditions, so that, regard-
less of your payload structure design, any people near the AIV can see it.
Buzzer
The warning buzzer should be checked for proper function. In order to maintain conformity
with applicable standards, it is important that the buzzer be audible in all operating con-
ditions and environments.
Warning Labels
See Figure 10-6. and Figure 10-7.
All warning labels on the LD Cart Transporter system should be checked on a weekly basis for
being present and legible. If any of the labels are missing or illegible, they should be replaced.
The labels, with part numbers, are:
l
Laser Aperture Label, 13308-000L
There is one laser warning label for each of the six lasers.
l
Pinch Point Label, 12992-000
