LD Cart Transporter User's Guide, 14766-000 Rev B
Page 152 of 190
Chapter 10: Maintenance
Lasers
Occasionally clean the lenses of all lasers. Use only alcohol-based, non-abrasive cleaners, and
wipe thoroughly.
Docking Station Contacts
The two docking station contacts occasionally need to be cleaned. The suggested interval is 3 –
6 months, depending on frequency of charging.
WARNING: Unplug power from the docking station before cleaning. Remove
the power cord at the charger.
Clean the contacts with isopropyl alcohol.
CAUTION: Do not lubricate the docking station paddle. Lubrication will
reduce the life of the paddle.
10.5 Accessing the Payload Bay
The payload bay is the area between the transporter top plate and the top of the platform itself.
Care must be taken, when accessing the payload bay, that the wires and connections between
the platform and the HMI post and coupling plate are not damaged. See Top View of an LD
Cart Transporter, Side Laser Support Tubes Removed on page 143.
The top plate is held on with eight M6 socket-head screws and two M5 cap screws. You
should not remove the HMI post base. The sheet metal cover of the Latching
Mechanismneeds to be removed to access the two M5 screws. The top plate and the rest of the
coupling plate will come off together.
CAUTION: When lifting the top plate off, take extra care not to scratch the
coupling laser’s lens with the top plate itself.
Removing Latching Mechanism Cover
1.
Remove the four M3 screws holding the Latching Mechanism cover to the top plate.
These go into four 45 mm standoffs in the top plate.
Retain the M3 screws for reassembly.
2.
Lift off the Latching Mechanism cover.
Retain the cover for reassembly.
