LD Cart Transporter User's Guide, 14766-000 Rev B
Page 187 of 190
Chapter 11: Technical Specifications
Cart
Description Specification
Physical
Length 592 mm (23.3 in.)
Width 846 mm (33.3 in.)
Height 480 mm (18.9 in.)
Weight 23 kg (50 lb)
Rating
Caster ESP ESP rated
Suspension
Passive Casters 2 front, 2 rear, spring-loaded
Caster diameter 100 mm (4 in.)nominal
Caster Brakes 2 rear casters
Docking Station
Description Specification
Current 8 A, thermal fuse built into power switch
Contacts 2
Voltage 100 to 240 VAC, 50 to 60 Hz
Power consumption 800 W
Short circuit current
rating (SCCR)
1500 A
Humidity 5 to 95% non-condensing
Temperature 5° to 40° C (41° to 104° F)
Dimensions - WxDxH
with Floor plate
349 x 369 x 315 mm (13.75 x 14.5 x 12.4 in.)
495 x 495.5 x 317 mm (16 x 19.5 x 12.5 in.)
Weight 8.2 kg (18 lb)
Mounting Directly to floor, wall bracket (included), or on floor
(free-standing) with included floor plate
Indicators Power on - blue
Charging - yellow
Connector For out-of-platform battery charging
