Omron NT31 Setup Manual

92
Connecting to the Host’s RS-232C Port Section 5-1
5-1-4 Recommended Connectors, Cables, and Crimp Terminals
Connectors and Cables Recommended for RS-232C
When making an RS-232C connecting cable, as far as possible use the rec-
ommended parts indicated in the table below. Some Units come supplied with
one connector and connector hood.
Check the required parts and prepare them in advance.
Cables with Connectors Made by OMRON
When connecting an NT-AL001 and a PLC, use the OMRON cables with con-
nectors indicated in the table below.
Note (1) The maximum tensile load of the recommended cable is 30 N. Do not ex-
ceed this load.
(2) After connecting a connecting cable, always tighten the connector
screws.
Name Model Remarks Delivered with
Connector XM2A-0901 9-pin type
Made by OMRON
CS/CJ-series CPU Units,
C-series CQM1, C200HS,
C200HX/HG/HE(-Z)E
CVM1/CV-series CPU
Units
CV500-LK201
XM2A-2501 25-pin type
Made by OMRON
C500-LK203
3G2A5-LK201-EV1
C200H-LK201-V1
DB-25P 25-pin type
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Connector
hood
XM2S-0911 9-pin type
Made by OMRON
CS/CJ-series CPU Units,
C200HS,
C200HX/HG/HE(-Z)E
CVM1/CV-series CPU
Units
CV500-LK201
XM2S-0913 Made by OMRON 9-pin ---
XM2S-0911-E Made by OMRON 9-pin CS/CJ-series CS1G/CS1H
XM2S-2511 25-pin type
Made by OMRON
C500-LK203
3G2A5-LK201-EV1
C200H-LK201-V1
DB-C2-J9 25-pin type
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Cable AWG28×5P
IFVV-SB
Multi-core shielded cable
Made by Fujikura, Ltd.
---
CO-MA-VV-SB
5P×28AWG
Multi-core shielded cable
Made by Hitachi, Ltd.
---
Model Cable Length Connector Specification
XW2Z-070T-1 0.7 m 9-pin ⇔ 9-pin
Host link, NT link (1:1), NT link (1:N)
+5 V power supplied from PLC
(Use when the PLC has a +5 V output.)
XW2Z-200T-1 2 m
