Operation Modes and the System Menu Section 6-3
6-3-2 Menu Tree
The System Menu allows the various functions of the NT31/NT31C to be exe-
cuted by using touch switches displayed on the touch panel. The menu tree,
starting from the System Menu, is shown below.
For details on System Menu operations, refer to 6-3-3 Operations with the
System Menu (page 138).
The menu tree may differ according to the system program installed in the
NT31/NT31C. The menu tree for the system program that is installed in the
NT31/NT31C on shipment is shown below.
SYSTEM INSTALLER MODE
SYSTEM MENU
I/O CHECK MENU
Quit
I/F Check
Device Check
I/F CHECK MENU
DEVICE CHECK MENU
MEMORY INIT. MENU
MEMORY
SWITCH MENU
I/O SETTINGS MENU
DISPLAY HISTORY MENU
ALARM HISTORY MENU
EXPANSION
MODE MENU
MAINTENANCE
MODE MENU
Quit
Transmit Mode (page 155)
Maintenance Mode
Expansion Mode
Exit System Installer
Download System Program (page 152)
Change System Settings (page 153)
Erase Screen Data (page 154)
Quit
Screen Data (page 140)
Display History (page 142)
Alarm History (page 144)
Recipe Table (page 146)
Memory Table (page 147)
Memory Switch (page 149)
Quit
Memory Init.
Memory Switch
I/O Settings
Calendar Check (page 195)
PT Settings (page 197)
Display History
Alarm History
Screen Data Disp. (page 202)
I/O Check
Start-up Wait Time (page 171)
Key Press Sound (page 171)
Buzzer Sound (page 172)
Printer Controller (page 173)
Print Method (page 175)
Screen Saver Movement (page 176)
Screen Saver Start up Time (page 178)
Hist. Disp. Method (page 180)
Resume Function (page 182)
Comm. Auto-return (page 184)
Time-out Interval (page 186)
Retry Counts (page 187)
Comm. A Method (page 159)
Comm. B Select (page 168)
Comm. B Method (page 159)
Quit
Version Display (page 228)
Programming Console Function (page 219)
Device Monitor Function (page 225)
Quit
Buzzer Check (page 206)
LED Check (page 207)
LCD Check (page 208)
Backlight Check (page 209)
Screen Memory (page 209)
Touch Switch (page 211)
Battery (page 213)
Quit
Sort by Occurrence (page 200)
Sort by Frequency (page 200)
Quit
Tool Comm. (page 214)
Comm. Port A (page 215)
Comm. Port B (page 215)
Printer (page 218)
Quit
Sort by Occurrence (page 198)
Sort by Frequency (page 198)
Quit
Contrast Adjust (page 191)
Brightness Adjust (page 193)
