Model List Appendix J
RS-232C/RS-422A Adapter
RS-232C Adaptor, RS-422A Adaptor
Related Parts and Equipment for PT
* The Support Tool indicated above includes the system installer and the standard system programs (Ver. 3.@/
Ver. 4.@) for the NT31, NT31C, NT631, and NT631C. System programs for the earlier NT30/620 PTs are also
included.
Cables with Connectors for PT ↔ PLC/NT-AL001-E
* The following PLCs can supply +5 V: C200HX/HG/HE(-Z)E, CQM1H, CPM2A, CPM2C, CS1G/H/D, and
CJ1G/H/M.
Model Specification
NT-AL001 RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
Model Specification
CPM1-CIF01 Links the RS-232C port of an NT31/NT31C and the peripheral port of a CPM1,
CPM2A, CPM2C, SRM1 (compatible with host link, and NT Link (1:1))
CPM1-CIF11 Links the RS-422A port of an NT31/NT31C and the peripheral port of a CPM1,
CPM2A, CPM2C, SRM1 (compatible with host link)
Name Model Remark
Support Tool* NT-ZJCAT1-EV4 Compatible with PC/AT personal computers
For Windows 95/98/NT4.0/2000/XP (English version)
CD-ROM
Options NT31C-CFL01 Replaceable backlight (common to NT31 and NT31C)
NT30-KBA04 Reflection suppressing protective sheet for NT31/NT31C
NT30-KBA01 Chemical-resistant cover for NT31/NT31C
NT-MF261 Memory Unit for NT31/NT31C
3G2A9-BAT08 Spare battery
Model Cable Length Applicable Units Communications Method Specification
XW2Z-200S 2 m Host Link Units with a 25-pin
connector
Serial port A host link
(RS-232C only)
9-pin ↔ 25-pin
XW2Z-500S 5 m
XW2Z-200T 2 m Host Link Units with a 9-pin con-
nector
Serial port A host link, NT Link
(1:1) (RS-232C only)
9-pin ↔ 9-pin
XW2Z-500T 5 m
XW2Z-200P 2 m Host Link Units with a 25-pin
connector
Serial port B host link
(RS-232C only)
25-pin ↔ 25-pin
XW2Z-500P 5 m
XW2Z-200S 2 m Host Link Units with a 9-pin con-
nector
Serial port B host link, NT Link
(1:1) (RS-232C only)
25-pin ↔ 9-pin
XW2Z-500S 5 m
XW2Z-070T-1 0.7 m CPU Units with a 9-pin connec-
tor (The PLC
(*1)
supplies +5 V
for NT-AL001-E connections.)
Host Link, 1:1 NT Link, or 1:N
NT Link using NT-AL001-E
9-pin ↔ 9-pin
XW2Z-200T-1 2 m
