133
System Menu Operation Flow Section 6-1
6-1 System Menu Operation Flow
Follow the procedure below when using the NT31/NT31C for the first time or
changing the system program.
Create the Screen Data Create the data to be displayed on the NT31/NT31C by using the Support
Tool.
For details on creating screen data, refer to the NT-series Support Tool Ver.
4.@ for Windows Operation Manual (V061-E1-@).
Start Up the NT31/NT31C
(Display the System
Menu) (page 133)
Turn ON the power to the NT31/NT31C.
If no screen data has been registered, an error message is displayed. In this
case, press the OK touch switch on the error message screen to display the
System Menu.
If screen data has been registered and the RUN mode is established, perform
the appropriate operations on the touch panel to display the System Menu.
Initialize the Memory
(page 140)
If necessary, initialize the memory of the NT31/NT31C by operation from the
System Menu.
Transmit the Screen Data
(page 155)
Connect the Support Tool to the NT31/NT31C and transmit the screen data
from the Support Tool to the NT31/NT31C.
For details on connecting the Support Tool, refer to 3-2 Connecting to the
Support Tool (page 33).
Set the Memory Switches
(pages 158, 169, 189)
Select the System Menu and set the operations of the NT31/NT31C — for
example the conditions for communications with the host — using the mem-
ory switches.
Start Operation (page 169) Connect the NT31/NT31C to the host and start operation.
System Maintenance
(page 191)
If an error occurs during operation, check the I/Os, settings, etc., by referring
to this guide.
6-2 Starting the NT31/NT31C
After checking that the hardware has been connected correctly, switch on the
power to the NT31/NT31C to start it up.
This section describes the operation of the NT31/NT31C when it is started up.
6-2-1 Operation at Startup
The NT31/NT31C operates as follows when the power is switched ON, or
when it is reset.
Initial Processing Self diagnosis — including a check on the internal memory of the NT31/
NT31C and a system program check — and the internal processing required
for startup, are performed.
If an error occurs during initial processing, an error screen is displayed.
If there is an error in the system program, the system program must be re-
installed. For details on the installation procedure, refer to 6-5 Operations in
the System Installer Mode.
To Next Page
