Omron R88D-1SN ECT Series User Manual

3 Specifications
3 - 26
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
The following table shows the allowable currents for each wire size.
Select wires carefully so that the specified allowable currents are not exceeded.
 600-V Heat-resistant Vinyl Wire (HIV)
Wire Sizes and Allowable Current (Reference)
AWG size
Nominal
cross-sec-
tional area
[mm
2
]
Configuration
[wires/mm
2
]
Conductive
resistance
[Ω/km]
Allowable current [A]
for ambient temperature
30°C 40°C 50°C
20 0.5 19/0.18 39.5 6.6 5.6 4.5
--- 0.75 30/0.18 26.0 8.8 7.0 5.5
18 0.9 37/0.18 24.4 9.0 7.7 6.0
16 1.25 50/0.18 15.6 12.0 11.0 8.5
14 2.0 7/0.6 9.53 23 20 16
12 3.5 7/0.8 5.41 33 29 24
10 5.5 7/1.0 3.47 43 38 31
8 8.0 7/1.2 2.41 55 49 40
6 14.0 7/1.6 1.35 79 70 57
4 22.0 7/2.0 0.85 99 88 70
