Omron R88D-1SN ECT Series User Manual

9 Details on Servo Parameters
9 - 42
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Sets the 2nd torque command filter.
• Selects whether to enable or disable the 2nd torque command filter.
 Description of Set Values
• Sets the cutoff frequency for the 2nd torque command filter.
• Sets the cutoff frequency for the 2nd torque command filter.
• This object is intended for PDO assignment. Use this object to change the Cutoff Frequency from a
PDO.
9-4-15 3234 hex: 2nd Torque Command Filter
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default
setting
Data
attri-
bute
Size Access
PDO
map
Complete
access
Modes of
opera-
tion
3234 --- 2nd Torque
Command Filter
--- --- --- --- --- --- --- Possible ---
00 Number of
entries
--- --- E1 hex --- 1 byte
(U8)
RO --- --- ---
01 Enable 0 to 1 --- 1 A 4 bytes
(INT32)
RW --- --- csp, csv,
cst, pp,
pv, hm
02 Cutoff Fre-
quency
10 to
50,000
0.1 Hz 1,536/
1,024
*1
*1. The first value is for the Servo Drive with its capacity 3kw or less. The second value is for the Servo Drive with its capacity
5kw or more.
A 4 bytes
(INT32)
RW --- --- csp, csv,
cst, pp,
pv, hm
E1 Cutoff Fre-
quency Com-
mand
10 to
50,000
0.1 Hz 1,536/
1,024
*1
A 4 bytes
(INT32)
W RxPDO --- csp, csv,
cst, pp,
pv, hm
Subindex 01 hex: Enable
Set
value
Description
0 Disabled
1 Enabled
Subindex 02 hex: Cutoff Frequency
Subindex E1 hex: Cutoff Frequency Command
