Setting Measurement Items
ZFX-C User’s Manual
3
SETTING THE MEASUREMENT CONDITIONS
91
Possible output results
The following values can be output when expressions are set.
Nos. indicating hue, saturation and value p.230
Item Description Message
Judgment result The judgment result is output. (0:OK, -1:NG, -2: not measured) Judge (JG)
Hue The hue average is output. (0 to 360.0) H average (H)
Saturation The saturation average is output. (0 to 100.0) S average (S)
Value The value average is output. (0 to 100.0) V average (V)
Hue deviation The hue fluctuation is output. (0 to 180.0) H deviation (HD)
Saturation deviation The saturation fluctuation is output. (0 to 50.0) S deviation (SD)
Value deviation The value fluctuation is output. (0 to 50.0) V deviation (VD)
Reference hue The hue when the measurement region is set is output.
(0 to 360.0)
Ref. H average (SH)
Reference saturation
The saturation when the measurement region is set is output.
(0 to 100.0)
Ref. S
average
(SS)
Reference value The value when the measurement region is set is output.
(0 to 100.0)
Ref. V average (SV)
Hue difference The hue difference obtained by "measurement value - reference
value" is output. (-360.0 to 360.0)
H average dif. (DH)
Saturation difference The saturation difference obtained by "measurement value -
reference value" is output. (-100.0 to 100.0)
S average dif. (DS)
Value difference The value difference obtained by "measurement value - reference
value" is output. (-100.0 to 100.0)
V average dif. (DV)
Reference hue deviation The hue fluctuation when the measurement region is set is
output. (0 to 180.0)
Ref. H deviation (SHD)
Reference saturation
deviation
The saturation fluctuation when the measurement region is set is
output. (0 to 50.0)
Ref. S deviation (SSD)
Reference value
deviation
The value fluctuation when the measurement region is set is
output. (0 to 50.0)
Ref. V deviation (SVD)
Hue deviation difference The hue deviation difference obtained by "measurement value -
reference value" is output. (-180.0 to 180.0)
H deviation dif. (DH)
Saturation deviation
difference
The saturation deviation difference obtained by "measurement
value - reference value" is output. (-50.0 to 50.0)
S deviation dif. (DSD)
Value deviation
difference
The value deviation difference obtained by "measurement value -
reference value" is output. (-50.0 to 50.0)
V deviation dif. (DVD)
Hue maximum/minimum The hue maximum/minimum values are output. (0 to 360.0) Max. H/Min. H
(HH, LH)
Saturation maximum/
minimum
The saturation maximum/minimum values are output. (0 to 100.0) Max. S/Min. S
(HS, LS)
Value maximum/mini-
mum
The value maximum/minimum values are output. (0 to 100.0) Max. V/Min. V
(HV, LV)
